Measurement Functions：ACA, ACV, DCV, Resistance, Diode, Buzzer Clamp Size：φ30mm or 10x35mm LCD Display：3 1/2 Digits LCD With 2000 Counts Applicable Circuit Voltage：AC 600V or less Sampling Reading Rate：3 Times/ Sec. Approx. Range：Automatic Applicable Height：Up to 2000m (above sea level) Auto Power Off：Approx. 15 Minutes Low Battery：Display on LCD Battery：AA A Battery 1.5V x2 Safety standard：IEC 61010-1 , IEC 61010-2-032 600V CAT III Pollution Degree 2
- Auto Power Off
- Auto Range
- MAX Hold
- Pocket Size
- High Accuracy
- 600A/600V Max.
MEASUREMENT RANGES
- 23°C±5°C, 80% R.H. MAX.) Accuracy：±(%rdg+dgt)
|
Measurement |
Range |
Resolution |
AVG Accuracy |
True RMS Accuracy |
Input Impedance |
Open-Loop Voltage |
|
DE-3103 |
DE-3103R |
|||||
|
(ACA) |
200A |
0.1A |
1.9%+10 |
──── |
|
|
|
600A |
1A |
1.9%+5 |
||||
|
|
2V |
0.001V |
1.5%+10 |
Approx 11MΩ |
|
|
|
20V |
0.01V |
Approx 10MΩ |
||||
|
200V |
0.1V |
1.5%+5 |
||||
|
600V |
1V |
|||||
|
|
200mV |
0.1mV |
0.7%+3 |
≥100MΩ |
|
|
|
2V |
0.001V |
1.3%+3 |
Approx 11MΩ |
|||
|
20V |
0.01V |
|||||
|
200V |
0.1V |
1%+3 |
Approx 10MΩ |
|||
|
600V |
1V |
|||||
|
|
200Ω |
0.1Ω |
1.5%+5 |
──── |
Approx >0.4V |
|
|
2kΩ |
0.001kΩ |
|||||
|
20kΩ |
0.01kΩ |
|||||
|
200kΩ |
0.1kΩ |
|||||
|
2MΩ |
0.001MΩ |
5%+5 |
||||
|
20MΩ |
0.01MΩ |
10%+5 |
||||
|
|
2V |
0.001V |
10%+5 |
──── |
Approx 1.5V |
|
|
|
200Ω |
0.1Ω |
The buzzer turns on for resistances lower than 90Ω±40Ω |
──── |
0.4V |
|
※Remarks: The accuracy data for ACA is subject to the conductor to be measured at the center of the iron core (clamp jaw)
TEMP./Humidity：
- Operation：0°C~ 50°C(32℉~122℉)/<80% R.H.(no condensation)
- Storage：-10°C~ 60°C(14℉~140℉)/<70%R.H.(no condensation)
Dimension & Weight：
- 189(L)x50(W,Max71)x30(H,Max47)mm
- Approx.200g (Including battery)
Accessories：
- Battery AAA 1.5V x2
- Instruction Manual x1
- Test Leads (red+black)for DE-3103/DE3103R x1
- Carrying case x1
Optional Accessories：
- AC Line Splitter(DE-10ALS)
